- 120mm suspension travel
- material: aluminium
- 29 wheelsize
- 148x12mm axle standard
- BB92 bottom bracket standard
Rahmengrössen S, M, L, XL
Farbe SILK BLUE (BLACK)
- Air
- 130mm suspension travel
- Tapered
- 44mm fork offset
- 29x2.6" max. wheelsize
- 32 teeth
- 170 mm-S, 175 mm-M up
Schalthebel Shimano SL -MT500-IL / Shimano Deore M6100
- 2 piston
- 180 mm
Steuersatz FSA NO.47/50
Innenlager Race Face BB BB92– Ø24mm
Spacer Plastic 10mm*2
Griffe MERIDA COMP EC
- 10-51 teeth
- 12 speed
- 29mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- 110x15mm width front hub
- 32 spoke holes
- Centerlock
- 148x12mm width rear hub
- 32 spoke holes
- Centerlock
- including removeable lever, 6/4mm allen key
Speichen Double Butted Black stainless
- 29x2.35"
- fold
- TR EXO Dual
Kette KMC X12
- 30.9mm diameter
- 0mm setback
- S: 100mm travel seatpost - M: 125mm travel seatpost - L/XL: 150mm travel seatpost
- V-mount
Sattelklemme MERIDA EXPERT
Zulässiges Gesamtgewicht 135 kg
| Rahmengröße | S | S | M | M | L | XL |
| Laufradgröße | 27.5" | 29" | 27.5" | 29" | 29" | 29" |
| ST Sitzrohrlänge (mm) | 400 | 400 | 440 | 440 | 480 | 520 |
| TT Oberrohrlänge (mm) | 571 | 572 | 593 | 592 | 614 | 637 |
| CS Hinterbaulänge (mm) | 430 | 435 | 430 | 435 | 435 | 435 |
| HTA Steuerrohrwinkel (°) | 66.8 | 67.3 | 66.8 | 67.3 | 67.3 | 67.3 |
| STA Sitzrohrwinkel effektiv (°) | 75 | 75.5 | 75 | 75.5 | 75.5 | 75.5 |
| BD Tretlagerabsenkung (mm) | 21 | 40 | 21 | 40 | 40 | 40 |
| HT Steuerrohrlänge (mm) | 105 | 95 | 115 | 95 | 105 | 115 |
| FL Gabeleinbaulänge (mm) | 522 | 541 | 522 | 541 | 541 | 541 |
| R Reach (mm) | 415 | 415 | 435 | 435 | 455 | 475 |
| S Stack (mm) | 581 | 607 | 590 | 607 | 616 | 626 |
| WB Radstand (mm) | 1130 | 1141 | 1154 | 1161 | 1185 | 1208 |
| SH Überstandshöhe (mm) | 698 | 707 | 726 | 730 | 759 | 787 |
