Weitere Informationen zu diesem Artikel finden Sie auf der
Homepage des Herstellers.
- 120mm suspension travel
- material: carbon/aluminium
- 29x2.35" max. wheelsize
- 148x12mm axle standard
- BB92 bottom bracket standard
Rahmengrössen S, M, L, XL
Farbe DARK STRAWBERRY (RACE RED)
- Air
- 130mm suspension travel
- Tapered
- 44mm fork offset
- 29x2.6" max. wheelsize
- 32 teeth
- 170 mm-S, 175 mm-M up
- Multi Release
- 2 piston
- 180 mm
Steuersatz FSA NO.47/50
Innenlager Shimano MT500-PA pressfit
Spacer Plastic 10mm*2
Griffe MERIDA EXPERT EC
- 10-51 teeth
- 12 speed
- 29mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- 110x15mm width front hub
- 32 spoke holes
- Centerlock
- 148x12mm width rear hub
- 32 spoke holes
- Centerlock
- including removeable lever, 6/4mm allen key
Speichen Double Butted Black stainless
- 29x2.4"
- fold
- TR EXO 3C MaxxTerra
- 29x2.3"
- fold
- TR EXO 3C MaxxTerra
Kette KMC X12
- 30.9mm diameter
- 0mm setback
- S: 100mm travel seatpost - M: 125mm travel seatpost - L/XL: 150mm travel seatpost
- V-mount
- incl. MERIDA minitool
Sattelklemme MERIDA EXPERT
Schutzbleche MERIDA MTB lite-front
Zulässiges Gesamtgewicht 135 kg
| Rahmengröße | S | M | L | XL |
| Laufradgröße | 29" | 29" | 29" | 29" |
| ST Sitzrohrlänge (mm) | 400 | 440 | 480 | 520 |
| TT Oberrohrlänge (mm) | 572 | 592 | 614 | 637 |
| CS Hinterbaulänge (mm) | 435 | 435 | 435 | 435 |
| HTA Steuerrohrwinkel (°) | 67.3 | 67.3 | 67.3 | 67.3 |
| STA Sitzrohrwinkel effektiv (°) | 75.5 | 75.5 | 75.5 | 75.5 |
| BD Tretlagerabsenkung (mm) | 40 | 40 | 40 | 40 |
| HT Steuerrohrlänge (mm) | 95 | 95 | 105 | 115 |
| FL Gabeleinbaulänge (mm) | 541 | 541 | 541 | 541 |
| R Reach (mm) | 415 | 435 | 455 | 475 |
| S Stack (mm) | 607 | 607 | 616 | 626 |
| WB Radstand (mm) | 1141 | 1160.7 | 1185 | 1208 |
| SH Überstandshöhe (mm) | 703 | 718 | 745 | 770 |
