- 100mm suspension travel
- material: carbon
- 29x2.3" max. wheelsize
- 148x12mm axle standard
- BSA bottom bracket standard
Rahmengrössen S, M, L, XL
Farbe ORANGE (BLACK)
- Air
- 100mm suspension travel
- Tapered
- Remote lockout
- 51mm fork offset
- remote lockout
- 32 teeth
- 170 mm-S, 175 mm-M up
Schalthebel JD-FL lever / Shimano Deore M6100
- 2 piston
- 2 piston
- flat mount
- 180 mm
- 160 mm
Steuersatz MERIDA 8151
Innenlager Shimano SM-BB52
Spacer Plastic 10mm*1, 5mm*2
Griffe Rock Shox TwistLoc grip
- 10-51 teeth
- 12 speed
- 22.8mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- 110x15mm width front hub
- 32 spoke holes
- Centerlock
- 148x12mm width rear hub
- 32 spoke holes
- Centerlock
- including removeable lever, 6/4mm allen key
Speichen Double Butted Black stainless
- 29x2.25"
- fold
- TR EXO
Kette KMC X12
- 30.9mm diameter
- 0mm setback
- S/M/L/XL: 100mm travel seatpost
- V-mount
- incl. MERIDA minitool
Sattelklemme MERIDA EXPERT
Zulässiges Gesamtgewicht 135 kg
| Rahmengröße | S | M | L | XL |
| Laufradgröße | 29" | 29" | 29" | 29" |
| ST Sitzrohrlänge (mm) | 400 | 440 | 470 | 500 |
| TT Oberrohrlänge (mm) | 576 | 596 | 619 | 643 |
| CS Hinterbaulänge (mm) | 435 | 435 | 435 | 435 |
| HTA Steuerrohrwinkel (°) | 68.5 | 68.5 | 68.5 | 68.5 |
| STA Sitzrohrwinkel effektiv (°) | 76.5 | 76.5 | 76 | 76 |
| BD Tretlagerabsenkung (mm) | 45 | 45 | 45 | 45 |
| HT Steuerrohrlänge (mm) | 95 | 95 | 105 | 115 |
| FL Gabeleinbaulänge (mm) | 503 | 503 | 503 | 503 |
| R Reach (mm) | 433 | 453 | 473 | 493 |
| S Stack (mm) | 585 | 585 | 595 | 604 |
| WB Radstand (mm) | 1126 | 1146 | 1169 | 1193 |
| SH Überstandshöhe (mm) | 730 | 731 | 736 | 738 |
