Weitere Informationen zu diesem Artikel finden Sie auf der
Homepage des Herstellers.
- 100 mm suspension travel
- material: carbon
- 29x2.35" max. wheelsize
- 148x12 mm axle standard
- BSA bottom bracket standard
Rahmengrössen S, M, L, XL
Farbe SILK BRONZE METAL (BLACK)
- Air
- 120 mm suspension travel
- Tapered
- 3 Pos lockout
- 44 mm fork offset
- 29x2.4" max. wheelsize
- adjustable low speed compression
- platform
- wireless
- T-Type
- 32 teeth
- 170 mm-S, 175 mm-M up
Schalthebel Sram AXS POD Controller
- 4 piston
- 2 piston
- 180 mm
- 160 mm
- Upper and lower IPS sealing
Innenlager Sram BB DUB BSA 73 MTB WIDE
Spacer 1*10 mm, 1*5 mm, 1*2.5 mm
Griffe MERIDA EXPERT EC
- 10-52 teeth
- 12 speed
- 110x15 mm width front hub
- 148x12 mm width rear hub
- 30/28 mm inner width
- Centerlock
- Sram XD
- material: carbon
- Tubeless ready (tubeless tape and valves included)
- Lifetime warranty
- including removeable lever, 6/4 mm allen key
- 29x2.3"
- fold
- TR EXO 3C MaxxTerra
- Flattop
- 30.9 mm diameter
- 0 mm setback
- S:125 mm travel seatpost - M 150 mm travel seatpost - L/XL 170 mm travel seatpost
- V-mount adapter
- incl. MERIDA minitool
Sattelklemme MERIDA EXPERT
- weighed at frame size M
- Weight may vary depending on bike size, finish or possible specification changes due to supply chain issues.
- Total weight of bike, rider and luggage
| Rahmengröße | S | M | L | XL |
| Laufradgröße | 29" | 29" | 29" | 29" |
| ST Sitzrohrlänge (mm) | 400 | 440 | 470 | 500 |
| TT Oberrohrlänge (mm) | 581 | 601 | 624 | 648 |
| CS Hinterbaulänge (mm) | 435 | 435 | 435 | 435 |
| HTA Steuerrohrwinkel (°) | 67 | 67 | 67 | 67 |
| STA Sitzrohrwinkel effektiv (°) | 75 | 75 | 75 | 74.5 |
| BD Tretlagerabsenkung (mm) | 36 | 36 | 36 | 36 |
| HT Steuerrohrlänge (mm) | 95 | 95 | 105 | 115 |
| FL Gabeleinbaulänge (mm) | 530 | 530 | 530 | 530 |
| R Reach (mm) | 420 | 440 | 460 | 480 |
| S Stack (mm) | 595 | 595 | 605 | 614 |
| WB Radstand (mm) | 1136 | 1156 | 1180 | 1203 |
| SH Überstandshöhe (mm) | 740 | 741 | 747 | 749 |
