- 171mm suspension travel mullet
- material: aluminium
- 29x2.5" max. wheelsize
- 148x12mm axle standard
- BSA bottom bracket standard
Rahmengrössen XShort, Short, Mid, Long, XLong
Farbe METALLIC BLACK (GREY/GREEN)
- Air
- 180mm suspension travel
- tapered
- 44mm Offset
- 29"
- coil
- spring rate: XS 300 lbs
- S 350 lbs, M: 400 lbs
- L: 450
- XL: 500
- 32 teeth
- 170 mm for all sizes
Schalthebel Shimano SL-MT500-IL / Shimano Deore M6100
- 4 piston
- 220mm
- 203mm
- Upper and lower IPS sealing
Spacer 2*10mm, 1*2.5mm
Griffe MERIDA EXPERT EC
- 10-51 teeth
- 12 speed
- 110x15mm width front hub
- 148x12mm width rear hub
- 30mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves included)
- front 29"
- rear 27.5"
- including removeable lever, 6/4mm allen key
Speichen Double Butted Black stainless
- 29x2.4"
- fold
- TR
- Enduro casing
- Soft Compund
- 27.5x2.4"
- fold
- TR
- Downhill Casing
- Soft Compound
Kette KMC X12
Kettenschutz MERIDA EXPERT TR ISCG05
- 34.9mm diameter
- 0mm setback
- all sizes 30-230mm travel seatpost
- 25% recycled material
- V-mount
Sattelklemme MERIDA EXPERT
- weighed at frame size M
- Weight may vary depending on bike size, finish or possible specification changes due to supply chain issues.
Zulässiges Gesamtgewicht 135 kg
| Rahmengröße | XShort | Short | Mid | Long | XLong |
| Laufradgröße | 29/27.5" | 29/27.5" | 29/27.5" | 29" | 29" |
| ST Sitzrohrlänge (mm) | 400 | 410 | 425 | 445 | 470 |
| TT Oberrohrlänge (mm) | 535 | 562 | 589 | 621 | 653 |
| CS Hinterbaulänge (mm) | 434 | 434 | 434 | 437.5 | 437.5 |
| HTA Steuerrohrwinkel (°) | 64 | 64 | 64 | 64 | 64 |
| STA Sitzrohrwinkel effektiv (°) | 79 | 79 | 79 | 79 | 79 |
| BD Tretlagerabsenkung (mm) | 7 | 7 | 7 | 27.5 | 27.5 |
| HT Steuerrohrlänge (mm) | 95 | 95 | 95 | 105 | 120 |
| FL Gabeleinbaulänge (mm) | 581 | 581 | 581 | 581 | 581 |
| R Reach (mm) | 415 | 442 | 470 | 498 | 525 |
| S Stack (mm) | 615 | 615 | 615 | 625 | 638 |
| WB Radstand (mm) | 1188 | 1215 | 1242 | 1275 | 1308 |
| SH Überstandshöhe (mm) | 735 | 740 | 743 | 740 | 735 |
