- 100mm suspension travel
- material: carbon
- 29x2.35" max. wheelsize
- 148x12mm axle standard
- BSA bottom bracket standard
Rahmengrössen S, M, L, XL
Farbe GREY (SILVER)
- Air
- 120mm suspension travel
- Tapered
- 3 Pos Remote lockout
- 44mm fork offset
- Large Volume aircan
- 3 Pos PTL remote lockout
- 32 teeth
- 170 mm-S, 175 mm-M up
- Multi Release
- 180mm
- 160mm
- Upper and lower IPS sealing
Spacer 1*10mm, 1*5mm, 1*2.5mm
Griffe Rock Shox TwistLoc grip
- 10-51 teeth
- 12 speed
- 25mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- 110x15mm width front hub
- 32 spoke holes
- Centerlock
- 148x12mm width rear hub, 32 spoke holes
- Centerlock
- including removeable lever, 6/4mm allen key
Speichen Double Butted Black stainless
- 29x2.4" WT
- tubeless ready
- 3C MaxxTerra EXO
- 29x2.25"
- fold
- TR EXO 120 TPI
Kette KMC X12
- 30.9mm diameter
- 0mm setback
- 150mm travel seatpost
- 6% recycled and 23% nature material
- V-mount
- incl. MERIDA minitool
Sattelklemme MERIDA EXPERT
- weighed at frame size M
- Weight may vary depending on bike size, finish or possible specification changes due to supply chain issues.
| Rahmengröße | S | M | L | XL |
| Laufradgröße | 29" | 29" | 29" | 29" |
| ST Sitzrohrlänge (mm) | 400 | 440 | 470 | 500 |
| TT Oberrohrlänge (mm) | 581 | 601 | 624 | 648 |
| CS Hinterbaulänge (mm) | 435 | 435 | 435 | 435 |
| HTA Steuerrohrwinkel (°) | 67 | 67 | 67 | 67 |
| STA Sitzrohrwinkel effektiv (°) | 75 | 75 | 75 | 74.5 |
| BD Tretlagerabsenkung (mm) | 36 | 36 | 36 | 36 |
| HT Steuerrohrlänge (mm) | 95 | 95 | 105 | 115 |
| FL Gabeleinbaulänge (mm) | 530 | 530 | 530 | 530 |
| R Reach (mm) | 420 | 440 | 460 | 480 |
| S Stack (mm) | 595 | 595 | 605 | 614 |
| WB Radstand (mm) | 1136 | 1156 | 1180 | 1203 |
| SH Überstandshöhe (mm) | 740 | 741 | 747 | 749 |
