- material: aluminium
- 180mm suspension travel
- 27.5" x 2.6" max. wheelsize
- 148x12mm axle standard
Rahmengrössen XShort, Short, Mid, Long, XLong
Farbe METALLIC BLACK (RIVER CLAY)
- Air
- 180mm suspension travel
- Tapered
- 44mm fork off set
- 29x2.6" max wheelsize
Federbein SR Suntour TRIAIR2
- 165mm for all sizes
Schalthebel Shimano SL -MT500-L / Shimano Cues U4000-9
- 4 piston
- 203mm
Steuersatz Acros ICR MERIDA EXTERNAL neck w/ Blocklock
Spacer 2*10mm, 1*2.5mm
Griffe MERIDA EXPERT EC
- 11-46 teeth
- 9 speed
- 110x15mm width front hub
- 148x12mm width rear hub
- 28mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- front 29"
- rear 27.5"
- 15x100mm width front hub
- 32 spoke holes
- Centerlock
- 12x148mm width rear hub
- 32 spoke holes
- Centerlock
- including removeable lever, 6/4mm allen key
Speichen Black stainless
- 29x2.5 "
- fold
- TR EXO+ 3C MaxxGrip
- 27.5x2.4 "
- fold
- 3C DD TR MaxxTerra
Kette Shimano LG500
Pedale VP VPE-533
- 34.9mm diameter
- 0mm setback
- XS: 125mm travel seatpost - S: 150mm travel seatpost - M/L: 200mm travel seatpost - XL: 230mm travel seatpost
- 28% recycled material
- V-mount
Sattelklemme MERIDA EXPERT
- reverse MERIDA Custom Mount
Rücklicht CG-404RG-BLK
Motor Bosch Performance Line CX
- removeable
Display Bosch Purion 200
| Rahmengröße | XShort | Short | Mid | Long | XLong |
| Laufradgröße | 29/27.5" | 29/27.5" | 29/27.5" | 29/27.5" | 29/27.5" |
| ST Sitzrohrlänge (mm) | 400 | 410 | 425 | 445 | 465 |
| TT Oberrohrlänge (mm) | 556 | 577 | 604 | 630 | 652 |
| CS Hinterbaulänge (mm) | 435 | 435 | 435 | 435 | 435 |
| HTA Steuerrohrwinkel (°) | 64.5 | 64.5 | 64.5 | 64.5 | 64.5 |
| STA Sitzrohrwinkel effektiv (°) | 78.5 | 78.5 | 78.5 | 78.5 | 78.5 |
| BD Tretlagerabsenkung (mm) | 12 | 12 | 12 | 12 | 12 |
| HT Steuerrohrlänge (mm) | 110 | 115 | 120 | 125 | 130 |
| FL Gabeleinbaulänge (mm) | 600 | 600 | 600 | 600 | 600 |
| R Reach (mm) | 415 | 435 | 460 | 485 | 505 |
| S Stack (mm) | 652 | 657 | 661 | 666 | 670 |
| WB Radstand (mm) | 1195 | 1218 | 1245 | 1272 | 1294 |
| Str Stack To Reach Ratio Pc | 1.57 | 1.51 | 1.44 | 1.37 | 1.33 |
