- material: aluminium
- 29"x2.4" with fender max. wheelsize
- 148x12mm axle standard
- intube
Rahmengrössen L, XL
Farbe EARLY MOSS GREY (BLUE)
- Air
- 120mm suspension travel
- 29x2.4" max wheelsize
- 165mm for all sizes
Schalthebel Shimano SL-MT500-L / Shimano Cues U6000-10
- 4 piston
- 180mm
Steuersatz Acros ICR MERIDA INTEGRATED neck w/ Blocklock
Griffe MERIDA EXPERT TK
- 11-48 teeth
- 10 speed
- 110x15mm width front hub
- 148x12mm width rear hub
- 28mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- 29"
- 15x100mm width front hub
- 32 spoke holes
- Centerlock
- 12x148mm width rear hub
- 32 spoke holes
- Centerlock
- including removeable lever, 6/4mm allen key
Speichen Black stainless
- 622-55
- wire
- reflecting line
Kette Shimano LG500
Pedale VP VPE-541P
- 34.9mm diameter
- 0mm setback
- S/M/L/XL: 150mm travel seatpost
*24% recycled material V-mount
Sattelklemme MERIDA EXPERT
Gepäckträger MERIDA MIK HD Carrier with Spring clip & Spanninga rear light
Schutzbleche Sunnywheel SW-FA311-65A/ SW-FA311-65E1
Parkstütze Massload CL-KA85
- reverse MERIDA Custom Mount
Rücklicht Spanninga Commuter Glow XE integrated in MERIDA MIK HD carrier
Motor Bosch Performance Line CX
- removeable
Display Bosch Purion 200
| Rahmengröße | L | XL |
| Laufradgröße | 28" | 28" |
| ST Sitzrohrlänge (mm) | 480 | 530 |
| TT Oberrohrlänge (mm) | 625 | 645 |
| CS Hinterbaulänge (mm) | 475 | 475 |
| HTA Steuerrohrwinkel (°) | 130 | 140 |
| STA Sitzrohrwinkel effektiv (°) | 67.5 | 67.5 |
| BD Tretlagerabsenkung (mm) | 62.5 | 62.5 |
| HT Steuerrohrlänge (mm) | 130 | 140 |
| FL Gabeleinbaulänge (mm) | 538 | 538 |
| R Reach (mm) | 441 | 459 |
| S Stack (mm) | 661 | 670 |
| WB Radstand (mm) | 1215 | 1237 |
| SH Überstandshöhe (mm) | 759 | 760 |
| Str Stack To Reach Ratio Pc | 1.49 | 1.45 |
| Seat Post Mounting Depth Max Mm | 300 | 300 |
