- material: carbon
- 29x2.4" max wheelsize
- 148x12mm axle standard
- BSA bottom bracket standard
Rahmengrössen S, M, L, XL, XXL
Farbe SILK GUNMETAL GREY (RED)
- Air
- 120mm suspension travel
- 2 position remote lockout
- 29x2.4" max. wheelsize
- 44mm fork offset
- wireless
- T-Type
- 34 teeth
- 170 mm-S, 175 mm-M up
Schalthebel JD-FL MX lever / Sram AXS POD Controller
- 2 piston
- 180mm
- 160mm
- Upper and lower IPS sealing
Innenlager Sram DUB BSA 73 MTB Wide
Spacer 1*10mm, 1*5mm, 1*2.5mm
Griffe MERIDA TEAM CC
- 10-52 teeth
- 12 speed
- 110x15mm width front hub
- 148x12mm width rear hub
- 30mm inner width
- Centerlock
- Sram 12 Speed
- material: carbon
- Tubeless ready (tubeless tape and valves included)
- Lifetime warranty
- including removeable lever, 6/4mm allen key
- 29x2.4" WT
- tubeless ready
- 3C EXO
- 29x2.4" WT
- tubeless ready
- 3C MaxxTerra EXO
- Flattop
- 30.9mm diameter
- 0mm setback
- S/M: 150mm travel seatpost - L/XL/XXL: 170mm travel seatpost
- V-mount adapter
- incl. MERIDA minitool
Sattelklemme MERIDA EXPERT
- weighed at frame size M
- Weight may vary depending on bike size, finish or possible specification changes due to supply chain issues.
| Rahmengröße | S | M | L | XL | XXL |
| Laufradgröße | 29" | 29" | 29" | 29" | 29" |
| ST Sitzrohrlänge (mm) | 380 | 410 | 440 | 470 | 500 |
| TT Oberrohrlänge (mm) | 594 | 614 | 637 | 659 | 681 |
| CS Hinterbaulänge (mm) | 430 | 433 | 436 | 439 | 442 |
| HTA Steuerrohrwinkel (°) | 66.9 | 66.9 | 66.9 | 66.9 | 66.9 |
| STA Sitzrohrwinkel effektiv (°) | 74.2 | 74.2 | 74.2 | 74.2 | 74.2 |
| BD Tretlagerabsenkung (mm) | 57 | 57 | 57 | 57 | 57 |
| HT Steuerrohrlänge (mm) | 95 | 95 | 105 | 115 | 125 |
| FL Gabeleinbaulänge (mm) | 530 | 530 | 530 | 530 | 530 |
| R Reach (mm) | 420 | 440 | 460 | 480 | 500 |
| S Stack (mm) | 614 | 614 | 624 | 633 | 643 |
| WB Radstand (mm) | 1132 | 1155 | 1182 | 1209 | 1235 |
| SH Überstandshöhe (mm) | 711 | 711 | 717 | 738 | 759 |
