- material: aluminium
- 27,5x2,25" max. wheelsize
- 135x9 mm axle standard
- internal
Rahmengrössen XS, S, M, L, XL
Farbe MATT SPARKLING GOLD (BLACK)
- Coil
- 80 mm suspension travel
- 27,5x2,4" max. wheelsize
- 38 teeth
- 165 mm
Schalthebel Shimano CUES U6000
- 2 piston
- 180 mm
Steuersatz MERIDA 8254
Spacer 10 mm*2
Griffe MERIDA EXPERT TK
Schalthebelklemme Cable Holder
- 11-48 teeth
- 10 speed
- 20 mm inner width
- material: aluminium
- 100x9 mm width front hub
- 32 spoke holes
- Centerlock
- 135x9 mm width rear hub
- 32 spoke holes
- Centerlock
Speichen Black stainless
- 27.5x2.25"
- wire
- reflecting line
Kette Shimano LG500
Kettenschutz Sunnywheel SW-CG-173A
Pedale VP VPE-891
- 30.9 mm diameter
- 15 mm setback
- 40 mm seatpost suspension travel
- V-mount
Sattelklemme MERIDA EXPERT
Gepäckträger MERIDA MIK HD Carrier with Spring clip
Schutzbleche Sunnywheel SW-FA-311-65(MSB)
Parkstütze Atranvelo ED-100-PC
Scheinwerfer Herrmans H-Black MR4 E
Rücklicht Spanninga Co mmuter Glow XE integrated in MERIDA MIK HD carrier
- 85Nm
Akku Trendpower Internal Battery 750Wh
Display Shimano SC-EN500
- weighed at frame size M
- Weight may vary depending on bike size, finish or possible specification changes due to supply chain issues.
- Total weight of bike, rider and luggage
| Rahmengröße | XS | S | M | L | XL |
| Laufradgröße | 27.5" | 27.5" | 27.5" | 27.5" | 27.5" |
| ST Sitzrohrlänge (mm) | 380 | 430 | 480 | 530 | 580 |
| TT Oberrohrlänge (mm) | 580 | 595 | 615 | 635 | 655 |
| CS Hinterbaulänge (mm) | 470 | 470 | 470 | 470 | 470 |
| HTA Steuerrohrwinkel (°) | 70 | 70 | 70 | 70 | 70 |
| STA Sitzrohrwinkel effektiv (°) | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| BD Tretlagerabsenkung (mm) | 65 | 65 | 65 | 65 | 65 |
| HT Steuerrohrlänge (mm) | 170 | 175 | 180 | 190 | 200 |
| FL Gabeleinbaulänge (mm) | 476 | 476 | 476 | 476 | 476 |
| R Reach (mm) | 385 | 399 | 417 | 435 | 452 |
| S Stack (mm) | 656 | 661 | 666 | 675 | 685 |
| WB Radstand (mm) | 1113 | 1129 | 1149 | 1170 | 1190 |
| SH Überstandshöhe (mm) | 403 | 403 | 402 | 402 | 401 |
