Weitere Informationen zu diesem Artikel finden Sie auf der
Homepage des Herstellers.
- material: aluminium
- 150 mm suspension travel
- 27.5x2.8" max. wheelsize
- 148x12 mm axle standard
- intube
Rahmengrössen XS, S, M, L, XL
Farbe BLACK (SILVER)
- Air
- 160 mm suspension travel
- Tapered
- 44 mm fork offset
- 29x2.8" max. wheelsize
- platform
- 34 teeth
Schaltwerk Sram NX Eagle
- 165 mm
Schalthebel Limotech RM10 (For Sram mmX) / Sram NX Eagle 12
- 4 piston
- 200 mm
Steuersatz MERIDA 8152
Spacer 2*10 mm, 1*2.5 mm
Griffe MERIDA EXPERT EC
Schalthebelklemme JAGWIRE FLEX-SL:CP
- 10-50 teeth
- 12 speed
- 28 mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- 110x15 mm width front hub
- 32 spoke holes
- 6 bolt
- 148x12 mm width rear hub
- 32 spoke holes
- 6 bolt
- including removeable lever, 6/4 mm allen key
Speichen Black stainless
- 29x2.4"
- wire
- 27.5x2.6"
- wire
Kette Sram SX Eagle
Pedale VP VPE-537
- 30.9 mm diameter
- 0 mm setback
- XS/S 100 mm travel seatpost - M/L 125 mm travel seatpost - XL 150 mm travel seatpost
- V-mount
Sattelklemme MERIDA EXPERT
Schutzbleche C093-02F + C093-02R
Scheinwerfer Lezyne E-Bike Power STVZO E115, reverse MERIDA Custom Mount
Rücklicht Chance Good USB CG-214RG
- 85Nm
- Shimano EN805 504Wh for XS only
Display Shimano SC-EN600
Switch Shimano SW-EN600-L
- weighed at frame size M
- Weight may vary depending on bike size, finish or possible specification changes due to supply chain issues.
- Total weight of bike, rider and luggage
| Rahmengröße | XS | S | M | L | XL |
| Laufradgröße | 29/27.5" | 29/27.5" | 29/27.5" | 29/27.5" | 29/27.5" |
| ST Sitzrohrlänge (mm) | 405 | 415 | 430 | 450 | 470 |
| TT Oberrohrlänge (mm) | 563 | 584 | 605 | 626 | 647 |
| CS Hinterbaulänge (mm) | 439.5 | 439.5 | 439.5 | 439.5 | 439.5 |
| HTA Steuerrohrwinkel (°) | 65.5 | 65.5 | 65.5 | 65.5 | 65.5 |
| STA Sitzrohrwinkel effektiv (°) | 75.5 | 75.5 | 75.5 | 75.5 | 75.5 |
| BD Tretlagerabsenkung (mm) | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 |
| HT Steuerrohrlänge (mm) | 110 | 115 | 120 | 125 | 130 |
| FL Gabeleinbaulänge (mm) | 571 | 571 | 571 | 571 | 571 |
| R Reach (mm) | 400 | 420 | 440 | 460 | 480 |
| S Stack (mm) | 633 | 633 | 638 | 642 | 647 |
| WB Radstand (mm) | 1170 | 1190 | 1212 | 1234 | 1256 |
| SH Überstandshöhe (mm) | 737 | 736 | 733 | 739 | 753 |
