Weitere Informationen zu diesem Artikel finden Sie auf der
Homepage des Herstellers.
- material: aluminium
- 133mm suspension travel
- 27.5x2.8" max. wheelsize
- 148x12mm axle standard
- intube
Rahmengrössen M, L, XL, XXL
Farbe SILK STEEL BLUE (GUNMETAL GREY)
- Air
- 140mm suspension travel
- Tapered
- 51mm fork offset
- 29x2.4" max wheelsize
- 34 teeth
Schaltwerk Shimano Deore RDM5100 11
- 165mm
Schalthebel Shimano SL -MT500-IL / Shimano Deore M5100 11
- 4 piston
Steuersatz MERIDA-8152 / MERIDA-8157 for M size
Spacer ACS92, 5mm*3
Griffe MERIDA EXPERT EC
Schalthebelklemme JAGWIRE FLEX-SL:CP
- 11-51 teeth
- 11 speed
- 29mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- 110x15mm width front hub
- 32 spoke holes
- Centerlock
- 148x12mm width rear hub
- 36 spoke holes
- Centerlock
- including removeable lever, 6/4mm allen key
Speichen Black stainless
- 29x2.4"
- wire
- DUAL
- 27.5x2.6"
- wire
- EXO
Kette KMC e11S EPT
Pedale VP VPE-537
- 30.9mm diameter
- 0mm setback
- S/M 100mm travel seatpost - L/XL 125mm travel seatpost - XXL 150mm travel seatpost
- V-mount
Sattelklemme MERIDA EXPERT clamp
Gepäckträger MERIDA MA006
Parkstütze Atranvelo ED-100-PC
Scheinwerfer LEZYNE E-BIKE POWER STVZO E115, reverse MERIDA Custom Mount
Rücklicht Herrmans H-Cargo integrated in MERIDA MIK carrier
- 85Nm
Display Shimano SC-EN600
Switch Shimano SW-EN600-L
| Rahmengröße | M | L | XL | XXL |
| Laufradgröße | 29/27.5" | 29/27.5" | 29/27.5" | 29/27.5" |
| ST Sitzrohrlänge (mm) | 415 | 430 | 450 | 470 |
| TT Oberrohrlänge (mm) | 581 | 603 | 624 | 645 |
| CS Hinterbaulänge (mm) | 439.5 | 439.5 | 439.5 | 439.5 |
| HTA Steuerrohrwinkel (°) | 66.5 | 66.5 | 66.5 | 66.5 |
| STA Sitzrohrwinkel effektiv (°) | 76.5 | 76.5 | 76.5 | 76.5 |
| BD Tretlagerabsenkung (mm) | 25 | 25 | 25 | 25 |
| HT Steuerrohrlänge (mm) | 115 | 120 | 125 | 130 |
| FL Gabeleinbaulänge (mm) | 551 | 551 | 551 | 551 |
| R Reach (mm) | 430 | 450 | 469 | 489 |
| S Stack (mm) | 627 | 631 | 635 | 640 |
| WB Radstand (mm) | 1182 | 1204 | 1226 | 1248 |
| SH Überstandshöhe (mm) | 730 | 727 | 733 | 747 |
