Weitere Informationen zu diesem Artikel finden Sie auf der
Homepage des Herstellers.
- material: aluminium
- 29x2.35" without fender max. / 29x2.25" with fender max. wheelsize
- 148x12 mm axle standard
- intube
Rahmengrössen S, M, L, XL
Farbe MATT EVERGREEN (GREEN)
- 100 mm
- Tapered
- 51 mm fork offset
- 29x2.4" max. wheelsize
- 34 teeth
- 165 mm
Schalthebel Shimano CUES U6000
- 2 piston
- 180 mm
Steuersatz MERIDA 8155
Spacer 10 mm*2
Griffe MERIDA EXPERT EC
- 11-48 teeth
- 10 speed
- 25 mm inner width
- material: aluminium
- 110x15 mm width front hub
- 32 spoke holes
- Centerlock
- 148x12 mm width rear hub
- 32 spoke holes
- Centerlock
- including removeable lever, 6/4 mm allen key
Speichen Black stainless
- 29x2.2"
- wire
Kette Shimano LG500
Pedale VP VPE-537
- material: aluminium
- 34.9 mm diameter
- 0 mm setback
- V-mount
Sattelklemme MERIDA EXPERT
Gepäckträger MERIDA MA008-1 w/spring clamp
Schutzbleche Sunnywheel SW-FA311-65A/ SW-FA311-65E1
Parkstütze Massload CL-KA98
Scheinwerfer Lezyne E-Bike Hecto STVZO E65
Rücklicht Spanninga Co mmuter GLOW XE
- 85Nm
Akku Trendpower Internal Battery 750Wh
Display Shimano SC-EN500
- weighed at frame size M
- Weight may vary depending on bike size, finish or possible specification changes due to supply chain issues.
- Total weight of bike, rider and luggage
| Rahmengröße | S | M | L | XL |
| Laufradgröße | 29" | 29" | 29" | 29" |
| ST Sitzrohrlänge (mm) | 380 | 430 | 480 | 530 |
| TT Oberrohrlänge (mm) | 588 | 605 | 625 | 645 |
| CS Hinterbaulänge (mm) | 465 | 465 | 465 | 465 |
| HTA Steuerrohrwinkel (°) | 67.5 | 67.5 | 67.5 | 67.5 |
| STA Sitzrohrwinkel effektiv (°) | 74.5 | 74.5 | 74.5 | 74.5 |
| BD Tretlagerabsenkung (mm) | 62.5 | 62.5 | 62.5 | 62.5 |
| HT Steuerrohrlänge (mm) | 115 | 120 | 130 | 140 |
| FL Gabeleinbaulänge (mm) | 527 | 527 | 527 | 527 |
| R Reach (mm) | 411 | 427 | 445 | 462 |
| S Stack (mm) | 636 | 640 | 650 | 659 |
| WB Radstand (mm) | 1165 | 1183 | 1204 | 1225 |
| SH Überstandshöhe (mm) | 719 | 750 | 794 | 835 |
